Layouts

Cheerz's layout features six selection boxes in Vial, corresponding to six different choices for layouts, which are:

• Left half of the first row ( in the image below)
• Right half of the first row ( in the image below)
• Left half of the third row ( in the image below)
• Right half of the third row ( in the image below)
• Left half of the spacebar row ( in the image below)
• Right half of the spacebar row ( in the image below)

• They appear as six independent selection boxes under the Layout tab in Vial.

• The left half of the first row can choose between Staggered or Ortholinear.

• The right half of the first row offers six options:

  • Staggered: 1.25× Enter, 2.25× Enter, 7U Enter, or BAE
  • Ortholinear: 1.25× Enter or 2.25× Enter

  Note: For BAE configuration, the physical switch must be installed in the ANSI Enter key position.

• Both halves of the third row can independently select between Staggered or Ortholinear layouts.

• Both halves of the spacebar row can independently select between 1u + 2.25u or 1.25u + 2u.

With all six sections independently configurable, you can freely combine them to create a fully customized layout tailored to your needs.
